Volar Leading Supplier of Industrial Machinery

Top Rebar Equipment Manufacturers and Suppliers in China

VLGW6-16B Intelligent steel bar bending machine

This equipment integrates functions such as straightening, sizing, clamping, and cutting, and is a multifunctional automated hoop reinforcement processing equipment. Can process hot rolled steel bars, with a maximum processing range of 4mm to 10mm for double lines; The range of single line machining is from medium mm to 12mm. Each minute, it can process 14-15 bars of 200 * 200mm, with a maximum production capacity of 1800 hoop shapes per hour. The processing graphics are visible, and the processing graphics are diverse. The electrical equipment is controlled by a programmable controller, ensuring the stability and reliability of the equipment, and the operation is simple and easy to learn.

Product features:
·Curved steel bar straightening mechanism prevents axial torsion of steel bars and ensures the best straightening effect of steel bars;
·Equipped with a manual traction mechanism, steel bar loading is convenient and fast;
·The equipment can bend round steel, tertiary steel, and ribbed threaded steel, with fast operating speed, high accuracy, and higher production efficiency;
·The perfect combination of functions such as straightening, sizing, bending, and cutting of steel bars truly realizes the multifunctional function of one machine;
·The equipment only requires one person to operate, saving labor costs and improving production efficiency;
·Changing the traditional manual multi link steel bar processing mode and adopting intelligent fully automatic production equipment to bend and shape the steel bar coil in one go greatly improves production efficiency and steel bar processing accuracy, frees up labor and reduces material consumption.

modelVLGW6-16B
Single line processing capabilityΦ6-16mm
Double line processing capabilityΦ6-12mm
Bending angle±1mm180°
Maximum traction speed120m/min
Maximum bending speed1150°/sec
Length accuracy±1mm
Angle accuracy±1°
Minimum hoop edge length≤100mm
Single machine single shift daily production capacity9T
Average power consumption7KW/h
communicationHaving remote network capabilities
Power outage memoryThe equipment is controlled by a programmable logic controller, with a backup power outage memory function. In case of a power outage, it can continue to work from the previous shutdown position on the next startup;
Maximum diagonal edge length of hoop reinforcement≤ 2400mm
Pre storageStore no less than 500 different product shapes
Processing quantity≤ 2
Air pressure≥ 0.6Mpa
Total power of equipment34KW
Reinforcement processing shape500 types
Total weight of the machine4t
Working environment temperature-5 ℃~40 ℃
Machine dimensions11970 * 2700 * 2950 (length * width * height)
Work levelFull load continuous production for 20 hours
