GQ40/50 Steel bar cutting machine ,Steel bar cutting machine

  • mechanical steel bar cutting machine:Small size and light weight, easy to transport and move.
  • Simple structure and easy operation.
  • Adopt high-speed standard motor, good quality, stable performance and longer service life
  • Adopt noise reduction device. When the cutting machine is working, its noise will not affect other workers.
  • The error is small, the performance is good, and the work efficiency is improved.

product name:Steel bar cutting machine

Steel bar cutter is a common steel bar processing machine, which is widely used for cutting various kinds of steel bars. Suitable for construction, airports, tunnels, culverts, bridges and other projects.

Product features:

1.Compact structure, solid and reliable
2. Good lubricating properties. Adopt closed structure, use Gear Splash lubrication, fill in 8-12kgsoil, the machine could work continuously for more than 3 month (oil level not lower than the oilcalibration, so that make sure the machine is in well lubrication condition)
3. Low power consumption, The gear uses roling bearing, low resistance, could save 1/3 powercomparing with otherrebar cutting machines



Machine modelGQ40GQ40 AGQ50 GQ50 A
Punching times32times/min32times/min28times/min28times/min
Cutting diameter of steel rod barsφ6-φ40mmφ6-φ40mmφ6-φ50mmφ6-φ50mm
Cutting diameter of rebarφ6-φ32mmφ6-φ32mmφ6-φ40mmφ6-φ40mm
Motor power3KW-2 P3KW-2 P4KW-2 P4KW-2 P
Cut off the maximum specification of flat steel70mm×15mm70mm×15mm80mm×18mm80mm×18mm
Whole machine quality400kg400kg580kg580kg
Cut off the maximum specification of square steel32mm×32mm32mm×32mm40mm×40mm40mm×40mm
Maximum specification for cutting angle steel50mm×50mm50mm×50mm63mm×63mm63mm×63mm
voltage380V380V380V380V
External dimensions1250mm×500mm×730mm1250mm×500mm×730mm1420mm×510mm×870mm1420mm×510mm×870mm
